Roswell Electric Drilling Machine

The Rasoul Electric Drilling Rig is a specialized and versatile drilling machine designed for construction, geotechnical, and exploration applications. It is engineered to perform precise, controlled drilling operations to depths of up to 50 meters. With a robust industrial structure and high-quality components, the rig delivers reliable, stable, and safe performance across a wide range of working conditions.

Thanks to its efficient power consumption, precise operational control, and relatively compact weight, this model is particularly well suited to medium-scale projects, drilling workshops, and field operations.

All major equipment and components required for this drilling system—including drill bits, drilling hammers, drill rods, and other connections and accessories—are manufactured and supplied by the same production group. This integrated supply approach helps ensure compatibility between components, easier access to replacement parts, and more effective technical support throughout drilling projects.

The Rasoul Electric Drilling Rig operates using an industrial three-phase electrical power supply, making it suitable for continuous drilling operations and demanding working environments.

The rig uses a rotary-percussive drilling system, enabling it to penetrate a wide range of hard and semi-hard ground formations. This combination makes it a dependable solution for construction, mining, and exploration projects.

For heavier-duty applications and continuous drilling under demanding conditions, the Rasoul Diesel Drilling Rig is also available. Its higher power output and diesel-powered configuration make it more suitable for intensive drilling operations.

Technical Specifications of the Rasoul Electric Drilling Rig

How the Rasoul Electric Drilling Rig Works

The Rasoul Electric Drilling Rig operates through a rotary-percussive drilling mechanism, in which rotary and impact forces work together to improve drilling efficiency.The two primary drilling actions are generated independently:

• Rotary movement: generated by the electric power unit and transmitted to the drill string.
• Percussive action: produced by a pneumatic drilling hammer powered by compressed air.

A key requirement for operating this drilling system is the use of an air compressor. The compressor supplies the compressed air required to operate the impact mechanism. Without a suitable compressed-air source, the percussive function of the drilling system cannot operate.

In simple terms:

• Rotary system → powered by the electric unit
• Impact system → powered by a compressed-air compressor

The combination of continuous rotation and percussion increases penetration capability in hard rock formations and can significantly improve drilling speed.

Applications of the Rasoul Drilling Rig
The Rasoul drilling system can be used for a variety of construction, mining, and geological applications, including:

• Construction projects such as dams, bridges, and foundation works
• Mining operations for blast-hole drilling and mineral extraction
• Drilling through hard rock and compact geological formations
• Road construction and tunneling projects
• Geotechnical and geological investigations
  Powdered rock sampling and preliminary ground investigation

Advantages of the Rasoul Electric Drilling Rig

• Drilling capability to depths of up to 50 meters
• Effective penetration in hard-rock formations
• Suitable for vertical, horizontal, and inclined drilling
• Quick setup and straightforward operation
• Suitable for construction, mining, and exploration projects
• Compact design for easier transportation and relocation
• Compatible with different types of drilling hammers

Request a Quote for the Rasoul Electric Drilling Rig
For information about the current price of the Rasoul Electric Drilling Rig, equipment availability, purchasing terms, or to arrange an on-site inspection, please contact our sales team:
